Mini 3W Underground Light
Mini 3W underground light
Product Introduction
Power:3W
Beam angle 40°
Luminous flux 280Lm
Color 80Ra
Optional color temperature 2700-6500K
Other light colors available red, blue, green, amber
LED brand BridgeLux COB
Input voltage and current DC12/24V, AC100-240Voptional
Operating temperature -25 ° ~ + 45 °
Protection IP67, IK08
Life 35,000h
Material :Stainless steel 304/316 collar+ Aluminum body
Energy efficiency class:F
Product Parameter
|
Item No. |
GA-UL3W |
|
Power |
3W |
|
LED chip brand |
For Bridgelux |
|
Luminous flux |
80lm/W |
|
CCT |
2700K, 3000K, 4000K, 6000K |
|
CRI |
80+ |
|
Beam angle |
55° |
|
Dimension |
Φ55XH63(mm)Diameter x length |
|
Warranty |
3Years |
|
Certifications |
CE, RoHS |
|
Input voltage |
AC100-240V,DC12V, DC24V optional |
|
Insulation class |
Class I |
|
Cable |
1 PC rubber cable 1M H05RN-F 3x1.0mm square |
|
Driver |
GreenArt |
|
IP rating |
IP67 Waterproof |
|
IK rating |
IK08 |
|
Housing |
Die-casting ADC#12 Aluminum |
|
Protection finishing |
Anti-corrosion coating 90~100 thickness |
|
Trim |
Stainless steel 304\316 |
|
Glass |
Step tempered Glass. T=8mm. |
|
Loading capacity |
500 kgs |
|
Cable Gland |
PG7 IP67 |
|
Gasket |
O-ring PMQ silicone seal |
|
Mounting Sleeve |
Anti-corrosion PVC. Black |
Product Details
Application
Widely use in outdoor, park, square, shipping mall, parking lot, pricate garden, ect.
Installation Precautions
• 1. When installing LED underground lights, the power must be cut off to ensure safety;
• 2. Before installing the LED underground light, check whether the connection of the LED underground light and its accessories is complete.
• 3. Before installing the LED underground light, dig trenches according to the installation size of the LED underground light, and then fix the embedded parts with concrete.
• 4. Before installing the LED underground light, prepare an IP67 or IP68 wiring device, and connect the external power input to the power cord of the light body. Moreover, the power cord of the LED underground light needs to have a VDE certified waterproof power cord to ensure the service life of the LED underground light.
About GREEN ART
10 years practical engineering experience give us sufficient but distinctive cognition to product no matter in Structure or installation, which also make us expert to providing customers with complete engineering solutions.
3,000㎡ workspace, 30 skilled workers, 2 automatic SMT machine, 1 automatic Packaging unit ,3 automatic aging lines ensure our monthly production capacity achieves 30,000pcs. We also own complete laboratory equipment like IES, integrating sphere, High-low temperature, IPX5-7, IPX5-8 waterproof testing system etc.
Factory
R&D department
We have very professional engineers with 10 years rich experice on development and research to expore new products to leads the markets.
Test lab
Quality control system
Examination from strict QC technicians, 6 engineers and customer service staffs to ensure good quality.
Aging test
Pre shipping inspection
Shipping
Production advantage
Certification
Exhibitions
FAQ
Q1: Are you trading company or manufacturer?
A: We are professional manufacturer specialized in outdoor lights for ground. And we trade our products with our clients directly.
Q2: Do you offer OEM service?
Yes. We offer OEM service.
Q3: Can I request to change the form of packaging and transportation?
A: Yes, we can change the form of the packaging and transportation according to your request, but you must bear their own costs incurred during this period and the spreads.
